Hydraulic Transmissions For Engine Power Forklift
| Match Engine Technique Parameter: | |
| Rating input power |
24~33kW
|
| Rating rotate speed |
2300r/min～2600r/min
|
| Hydraulic Transmissions Parameter: | |
| Drive ratio (go forward / fall back ) |
19.2065
|
| Circumgyrate way |
clockwise (look on input port)
|
| Work oil |
20＃steamship machine oil (or 6＃、8＃hydraulic transmissions oil )
|
| Oil temperature |
70℃～95℃
|
| Max. outline dimension |
740mm×470mm×450mm
|
| Torque Convertor Parameter: | |
| Max. torque ratio |
K0=3.15
|
| Pump ring diameter |
￠265mm
|
| Tiptop efficiency |
ηmax=0.79
|
| Enter oil pressure |
0.5~0.7 Mpa
|
| Rated torque at max. efficiency |
MBgη=31N.m
|
The torque convertor is integrated with gearbox, it could be changed by different engine. More information, please contact us!
